Module Mounting Structure

Module mounting structures play a very important role in efficient working of a solar power plant. While most of the components of balance of system (BOS) such as inverter DC cables junction boxes transformers, etc. are readily bought from the equipment suppliers the workmanship of an EPC contractor is reflected mainly through module mounting structures and wiring management

following steps are required for installing Mouinting structur

  • Structural Analysis – Analysis of wind loads and dead loads using STAAD Pro. Data from on-site pull-out tests is utilized to finalize foundation depths.
  • 2D drafts of General Arrangement and Structural Members, using AutoCAD
  • 3D checks of 2D components, using SolidWorks • Review, Final Checks and Final Approval.
  • Finite Element Analysis of individual structural members or specific connections is performed to further corroborate the stability of the structural design.
